MEG-BATT-1 5.12kWh Ultra Slim LiFePO Battery Scalable, IP55 Rated

Description:

The MEGATRON is an advanced ultra-slim lithium iron phosphate (LiFePO) battery module designed for high-performance energy storage. With a compact form factor, extended cycle life, and scalable architecture, it is ideal for residential, commercial, and backup power systems requiring reliable and space-saving battery integration.

Core Specifications

• Battery chemistry: Lithium Iron Phosphate (LFP 16S)
• Nominal capacity: 5.12kWh
• Usable capacity: 4.86kWh (95% Depth of Discharge)
• Nominal voltage: 51.2V
• Operating voltage range: 43.2V 58.4V
• Max charge voltage: 58.4V

Performance & Safety

• Max. charge current: 100A
• Max. discharge current: 150A
• Protective class: Class 1
• Ingress protection: IP55 (dust and water resistant)
• Designed for indoor environments up to 2000m altitude
• Compact and lightweight: 49kg | 780mm × 698mm × 68mm

Communication & Integration

• Supports RS485, CAN, RS232, and dry contact interfaces
• Seamless integration with compatible inverters and energy systems
• Max scalability: Up to 16 units in parallel (81.92kWh total capacity)

Durability & Lifecycle

• 6000 cycles at 25°C with 60% end-of-life capacity
• 10-year design life under standard usage conditions
• Certified to CE, IEC62619, and UN38.3 for safety and transport compliance

Operating Conditions

• Charging temperature: 0°C to 50°C
• Discharging temperature: -20°C to 60°C
• Recommended storage temperature: -10°C to 35°C
• Humidity tolerance: 95% RH (non-condensing)

Warranty

This battery includes a 10-year limited performance warranty.
Note: Installation must be performed by a certified professional in accordance with SANS 10142 standards. A valid Certificate of Compliance (COC) and proof of qualified installation must be retained for any warranty claims.
